Tractor Box Blade Ripper Shank Agricultural Machinery Land Leveler
Box-type motor grader
This machine uses a scraper blade mounted between the front and rear wheels for land leveling. It also features lift, tilt, swivel, and reach functions. Its flexible and precise movements make it easy to operate. It is suitable for roadbed and pavement construction, ditch excavation, pavement mixture mixing, snow removal, granular material transportation, and dirt and gravel road maintenance. This grader blade is ideal for land leveling, soil work, snow removal, livestock shed cleaning, and other tasks. It connects to the tractor's three-point rear hitch.
The blade, mounted between the front and rear wheels, is used for leveling the ground. It can be raised, lowered, tilted, rotated, and extended for precise and flexible operation. It is suitable for roadbed and pavement construction, trenching, mixing materials, snow removal, grain transport, and dirt and gravel road maintenance. The leveling blade is equipped with a primary hitch. It is recommended for use with tractors ranging from 25 to 120 horsepower.
3 point linkage box scraper
The box blade has following features:
* Height adjustable and removable tynes
* Extra strong frame designed for long life operation
* Removable rear grading blade
Our graders are designed to deliver precise and efficient earthmoving, perfect for grading roads, grading roads, and a variety of other construction tasks.
Box Grader Blade With Ripper Heavy Duty Tractor
Box Blade Level Undulating Ground Tractor Box Blade Land Scraper Cultivator
Box-type working attachment
Unlike traditional grader scraper designs, this type of working device usually consists of a box structure with a certain volume (or a combination of scraper and bucket functions) that can hold and push soil, allowing for large-area, continuous leveling operations and minimizing soil accumulation or leakage.
Automated control system
Equipped with high-precision sensors (such as GPS, Beidou positioning system, and inclination sensors), controllers, and actuators. The sensors collect real-time data on land elevation and flatness. The controller automatically adjusts the height, angle, and propulsion speed of the working attachment based on preset leveling criteria (such as slope and elevation difference), eliminating the need for frequent manual operation.
high quality Chassis
Most often use crawler or wheeled chassis. Crawler chassis are suitable for soft soil (such as farmland and wetlands) to reduce ground pressure, while wheeled chassis are suitable for hard surfaces (such as sites and road foundations) and offer faster movement. The chassis generally offers excellent maneuverability, adapting to complex terrain, turns, and slopes.
Power system
Equipped with a high-horsepower diesel engine to provide power for the working device and travel system, while meeting the energy needs of the automation equipment and ensuring stability under heavy loads and long-term operations.
the box-type automatic leveler has significant advantages
High-Precision Leveling
Utilizing an automated control system, land leveling errors are kept to extremely low levels, meeting high-standard operational requirements (e.g., ensuring slope uniformity for irrigation to prevent water accumulation; ensuring the levelness of factory foundations to ensure subsequent construction quality).
Efficient Operation
Automated operation reduces manual intervention, enabling daily operations of up to thousands of square meters (depending on equipment size and terrain), far exceeding the efficiency of manual labor or traditional machinery, making it particularly suitable for large-scale land preparation.
Reduced Labor Costs
Continuous monitoring and adjustments by skilled operators are unnecessary, requiring only one or two additional personnel for oversight (e.g., equipment inspections and obstacle clearance), saving manpower.
Adaptable
Preset parameters (e.g., slope 1:100, elevation ±5cm) can be configured to meet specific operational requirements, flexibly addressing the leveling requirements of diverse scenarios, including farmland, fish ponds, construction sites, and airport runways.
|
Model
|
BB-4
|
BB-5
|
BB-6
|
BB-7
|
|
Working Width (mm)
|
1220
|
1530
|
1830
|
2135
|
|
Overall Depth (mm)
|
547
|
547
|
547
|
547
|
|
Matched Power (HP)
|
18-25
|
20-25
|
25-40
|
30-40
|
|
Weight (kg)
|
135
|
170
|
206
|
229
|
|
Package Size (mm)
|
1320*600*500
|
1620*600*500
|
2000*600*500
|
2220*600*500
|
|
Volume (cbm)
|
0.396
|
0.486
|
0.6
|
0.66
|
|
20 GP (set)
|
52
|
48
|
48
|
48
|
|
Linkage
|
Three-point mounted
|
|||
Box-type Motor Grader Application Scenarios
Farmland Leveling: Creates a uniform surface for irrigation and seeding, improving water resource utilization and crop growth consistency (for example, the levelness of rice fields directly impacts irrigation efficiency).
Terracing: In hilly areas, automated control enables precise slope design of terraces to prevent soil erosion.
Water Conservancy Projects: River and Canal Leveling: Ensures water delivery efficiency for water conservancy facilities and reduces siltation or erosion caused by uneven terrain.
Municipal and Industrial Construction: Site Leveling: Provides a level foundation for projects such as houses, factories, and parking lots, reducing subsequent foundation treatment costs.
Roadbed Leveling: Ensures the flatness of the base layer during road construction, extending the service life of the road surface.
Selection Considerations
Operating Area and Accuracy Requirements: Small or medium-sized equipment is recommended for small plots (such as greenhouses and small farmlands).
For high-precision requirements (such as greenhouse nurseries), models with RTK differential positioning (with centimeter-level accuracy) are preferred.
Terrain Adaptability: Tracked models are preferred for soft terrain, while wheeled models are recommended for hard terrain or when quick relocation is required.
After-Sales Service: Automation systems involve precision components such as sensors and controllers. Choose products from reputable service providers with a robust network of service providers to ensure timely troubleshooting and system upgrades.
Wide Range of the Farm Implement
Our main products consist of disc ploughs, disc harrows, share ploughs, rotary tillers, rotary stubble crushers, wheat planters, corn planters, single disc planters, middle cultivators, soil ridgers, soil loosening wheat and rice machines, harvesters, wheat and corn threshers, tractor trailers, slashers, gearboxes, plough and harrow discs, cultivation chisels and points, and hand tools. Moreover, we also can supply other products according to customers' drawings and samples. We will satisfy our customers with our best products and services.
Our products range: rotary tiller, backhoe, mower, post hole digger, wood chipper, log splitter, box blade with rippers and so on (30 series and more than 200 models). Leadray's implements are CE and ISO 9001 certified and our products are mainly exported to North America, South America, Europe, Asia, etc. We get a good reputation from the worldwide customers.
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
