Mini Tractor in Pakistan,50hp 4wd China Tractor
This 50hp 4wd mini tractor is designed for versatile agricultural tasks, offering reliable performance with a mechanical sliding sleeve differential lock and hydraulic steering for 4wd models.
Diesel tractors 50hp robust frame and precision-engineered components ensure long-term durability and operational efficiency. Equipped with a single, dry, single-stage clutch and partial separated lifter hydraulic system, it supports easy maintenance and high precision.
The PTO speed is 540/760/1000rpm, the gearbox has two options: 8F+4R/16F+8R (optional), the hydraulic output valve is a multi-way valve (optional), and the lifting force (at 610mm point) is 12kN.
The 50hp Captain Mini Tractor, designed for small farming and garden use, features a 4-cylinder water-cooled engine ensuring energy-saving performance and stability.
The transmission system is 8+2 gears, and the tire sizes are available in 6.0-16/9.5-24 and 6.50-16/11.2-24.
The wheelbase is 1800mm or 1870mm, and the maximum rated traction is ≥8.5kN/≥15.9kN. It is suitable for scenarios such as orchards, small and medium-sized farms, and road transportation.
| Basic configuration | |||
| Model | Diesel Tractors 50hp / 504hp | ||
| Dimensions | Length×Width×Height(mm) | 3615×1750×2150 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1300 | |
| Rear Wheel(mm) |
1300-1500 1300 nomally |
||
| Min.Ground Clearance(mm) | 325 | ||
| Dry Mass | Complete tractor weight(KG) | 2280 | |
| Engine | Trade Mark or Brand | JIANGDONG/XINCAI | |
| Engine Model | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 29.4KW | ||
| Rated Speed(r/min) | 2200(YCD4J11T-65),2300(YT4A2-23) | ||
| Fuel Tank | Volume(L) | 43 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear Box | F8+R4 | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Mechanical,dry type | ||
| Running System | Tyre Model | F/R(2WD) |
6.0-16/ 12.4-28 |
| F/R(4WD) |
8.3-20/ 12.4-28 |
||
| Steering System |
Mechanical for 2wd tractor and Hydraulic steering for 4wd tractor |
||
| Working Device | Hydraulic System Type | Partial seperated lifter | |
| Linkage Type | I Rear Mount 3-point Linkage | ||
| PTO(Standard) | Φ38×8 or Φ35×6 or Φ34.67×21 | ||
| PTO Speed(r/min) | 540/760 | ||
| Drawbar Type | Fixed Drawbar | ||
| Optional configuration | |||
| Cab with Heater | Multiple Unit Valve | ROPS | Sunvisor |
| Adjustable Comfort Seat | Paddy Tyre | Heater | Swing Drawbar |
| PTO Speed(r/min):540/1000 760/1000 | |||
| Bob-weight | Frontballest |
8×10=80kg 10kg/pcs |
|
| Rearballast |
2×30=60kg 30kg/pcs |
||
Tractors for Agriculture 50hp 4wd 4x4 Tractor
The vehicle's overall dimensions are approximately 3700 mm (1560 mm) and 2400 mm (2400 mm).
The wheelbase is 1860 mm, the minimum ground clearance is 400 mm, the minimum operating weight is approximately 1500 kg (1500 kg), and the fuel tank capacity is 60 liters.
The engine is a Weichai WP3.2, with a rated power of 36.8 kW (50 hp) and a rated speed of 2400 rpm.
The transmission features an 8+8 shuttle shift mechanism, with power take-off shaft speeds of 540/720 rpm.
The front axle is a fully sealed, maintenance-free, dual-use axle for both water and land use, while the rear axle is a highly reinforced T-type axle.
The hydraulic system is equipped with two hydraulic multi-way valves for forced lifting and lowering.
Powered by a 50hp diesel engine, this machine features an open cab design that provides excellent visibility and ventilation. Its efficient design ensures maximum productivity and minimal fuel consumption, making it suitable for medium-sized farm operations and compatible with a variety of agricultural tools, including plows, seed drills, and cultivators.
We have CE Certificate,SGS Product Certificate, ISO9000 Quality Control Certificate and BV Supplier Certificate, Our machine had win much good reputation through its quality and nice performance.
Nowadays Our products have been exported to 127 countries and regions over the world.
Regarding after-sales service
Our engine transmission comes with an indefinite warranty to ensure your user experience.
